ES802 |
ESII2508 |
ESII2508 |
ES3012 |
ES3512 |
ES4013 |
ES6020 |
ES8525 |
ES1253 |
EHM1303 |
EHM2204 |
|
長mm |
960 |
1350 |
1350 |
1750 |
1640 |
1600 |
2700 |
3240 |
3450 |
3530 |
4560 |
|
寬mm |
800 |
1050 |
1050 |
1100 |
1400 |
1400 |
1360 |
1400 |
1680 |
1600 |
1800 |
|
高mm |
1850 |
2330 |
2330 |
2440 |
2550 |
2550 |
2590 |
2665 |
2800 |
2700 |
2900 |
|
開口高mm |
360 |
370 |
370 |
370 |
420 |
420 |
420 |
470 |
500 |
470 |
470 |
|
開啟高mm |
240 |
250 |
250 |
250 |
300 |
300 |
300 |
350
|
380 |
350 |
350 |
|
喉深mm |
135 |
200 |
200 |
110 |
260 |
410 |
355 |
400 |
465 |
450 |
447 |
|
側板間距mm |
200 |
820 |
820 |
1220 |
1120 |
960 |
1900 |
2380 |
2440 |
2570 |
3000 |
|
工作臺高mm |
960 |
880 |
880 |
940 |
940 |
970 |
940 |
940 |
960 |
950 |
950 |
|
加壓能力T |
8 |
25 |
25 |
30 |
35 |
40 |
60 |
85 |
125 |
130 |
220 |
|
工作臺長度mm |
200 |
800 |
800 |
1200 |
1200 |
1300 |
2000 |
2500 |
3000 |
3000 |
4000 |
|
折彎行程mm |
70 |
100 |
100 |
100 |
150 |
150 |
150 |
150 |
200 |
200 |
200 |
|
后定位行程mm |
100 |
300 |
300 |
300 |
500 |
500 |
500 |
500 |
600 |
600 |
600 |
|
整機功率KW |
4.7 |
11.4 |
11.6 |
11.2 |
14.2 |
15.2 |
31.5 |
31.6 |
31.8 |
9.4 |
16 |
|
整機重量T |
0.7 |
1.9 |
1.9 |
2.5 |
3.5 |
3.7 |
5.4 |
8.3 |
13.5 |
8.2 |
16.5 |
|
控制軸數 |
2軸 |
4軸 |
6軸 |
3軸 |
6軸 |
6軸 |
6軸 |
6軸 |
6軸 |
6+1軸 |
6+1(8+1)軸 |
|
D1 軸精度 |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
±0.01 |
±0.01 |
|
D2 軸精度 |
/ |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
±0.005 |
±0.01 |
±0.01 |
|
L 軸精度 |
±0.01 |
±0.01 |
±0.01 |
±0.01 |
±0.01 |
±0.01 |
±0.01 |
±0.01 |
±0.01 |
±0.01 |
±0.01 |
|
Z 軸精度 |
/ |
±0.1 |
±0.1 |
/ |
±0.1 |
±0.1 |
±0.1 |
±0.1 |
±0.1 |
±0.1 |
±0.01 |
|
Y1 軸精度 |
/ |
/ |
±0.1 |
/ |
±0.1 |
±0.1 |
±0.1 |
±0.1 |
±0.1 |
±0.1 |
±0.01 |
|
Y2 軸精度 |
/ |
/ |
±0.1 |
/ |
±0.1 |
±0.1 |
±0.1 |
±0.1 |
±0.1 |
±0.1 |
±0.01 |
|
D1/D2軸接近速度 |
150mm/s |
200mm/s |
200mm/s |
200mm/s |
200mm/s |
200mm/s |
200mm/s |
150mm/s |
150mm/s |
200mm/s |
200mm/s |
|
D1/D2軸折彎速度 |
0.2-50mm/s |
0.2-50mm/s |
0.2-50mm/s |
0.2-50mm/s |
0.2-50mm/s |
0.2-50mm/s |
0.2-50mm/s |
0.2-50mm/s |
0.2-50mm/s |
0.2-15mm/s |
0.2-15mm/s |
|
D1/D2軸回程速度 |
150mm/s |
200mm/s |
200mm/s |
200mm/s |
200mm/s |
200mm/s |
200mm/s |
150mm/s |
150mm/s |
200mm/s |
200mm/s |
|
L 軸移動速度 |
500mm/s |
500mm/s |
500mm/s |
500mm/s |
500mm/s |
500mm/s |
500mm/s |
500mm/s |
500mm/s |
500mm/s |
500mm/s |
|
Z 軸移動速度 |
/ |
250mm/s |
250mm/s |
/ |
125mm/s |
125mm/s |
62mm/s |
62mm/s |
62mm/s |
62mm/s |
62mm/s |
|
Y1 軸移動速度 |
/ |
/ |
700mm/s |
/ |
700mm/s |
700mm/s |
700mm/s |
700mm/s |
700mm/s |
700mm/s |
700mm/s |
|
Y2 軸移動速度 |
/ |
/ |
700mm/s |
/ |
700mm/s |
700mm/s |
700mm/s |
700mm/s |
700mm/s |
700mm/s |
700mm/s |
